CISCO SPA500S Expansion Module

$ 98.99 Inc-Gst

Available Stock (QTY: 50+)



1 Year Nationwide Warranty

Extended warranties available

Prices Exclude Shipping

PSU Not Included



CISCO SPA500S – 32 Button Expansion Module (Attendant Console) for CiscoSPA500 Series IP Phones



Highlights

  • Easy to install, and designed exclusively for the Cisco® SPA 500 Series IP Phones
  • 32 programmable buttons simplify dialling and call transfers
  • Multicolored LEDs monitor the status of each configured voice line via Busy Lamp Field (BLF)
  • Two attendant consoles can be linked, for a total of 64 buttons



Product Overview

The Cisco ® SPA500S Expansion Module (Figure 1) is part of the Cisco Small Business Pro Series and designed for use with the Cisco SPA500 Series IP Phones. It is an ideal solution for small businesses wanting to simplify incoming call handling by quickly directing calls to the requested party and also to monitor line status from a central location.

The attendant console easily attaches to a SPA500 Series IP Phone, providing 32 programmable speed-dial or direct station select (DSS) buttons, each illuminating the line’s status (idle, ringing, busy, or null) via the BLF. Incoming calls can immediately be transferred to the proper location with the push of a button assigned to the extension.

The modular design of the Cisco SPA500S permits up to two attendant consoles to be deployed, for a total of 64 buttons, offering an affordable solution that expands with the growth of your voice network. Installation and setup is just a matter of connecting the supplied bracket and cable to the attendant console, which uses the phone’s power supply; no additional power source is required.

Based on the Session Initiation Protocol (SIP), the Cisco SPA500S has been tested to ensure comprehensive interoperability with equipment from voice over IP (VoIP) infrastructure leaders, enabling service providers to offer competitive, feature-rich services to their customers.



Features

  • 32 programmable multicolored LED buttons
  • Illuminated line status monitoring (green for idle, red for in use, blinking red for ringing, orange for registration error)
  • Call transfer
  • Speed dial
  • DSS
  • Busy lamp field
  • One-touch transfer
  • Call pickup



Specifications

Ports. 2 auxiliary ports

Buttons. 32

LEDs. Multicolored: green, red, orange



Documentation

  • Quick Installation Guide
  • User Guide
  • Administration Guide
  • Provisioning Guide (for service providers only)



Environmental

Dimensions. 101 Wide x 201 High x 39 mm Deep

Unit weight. 2 lb (0.9 kg)

Power. Provided by host Cisco SPA 500 Series IP phone



Certification

FCC, cUL, CE, Canadian Interference-Causing Equipment Standard ICES-003



Operating temperature

41º to 113ºF (0º to 40ºC)



Storage temperature

-13º to 185ºF (-40º to 70ºC)



Operating humidity

5% to 95% noncondensing, operating and nonoperating

Storage humidity

5% to 95% noncondensing, operating and nonoperating
