iWolf WC8350GSM Cellular Mobile PBX System Starter Kit

250 Extensions

In Stock ( 15+)

10% off with installation



$ 2897.00 Inc-Gst

2 Year Nationwide Warranty

1 Year Support

Extended warranties available



WC8350GSM 3G/4G Cellular Mobile and Wi-Fi IP PBX System Starter Kit

Install it Yourself or get us to do it for you !



Sales, Installation, Maintenance and Support.



Enjoy “Total Portability” using a 3G GSM IP PBX system with Wi-Fi Handsets,

Why pay thousands of dollars to upgrade your network cabling system.

If your workplace lacks the connective infrastructure required to install a new phone system use this 3G GSM Telephone System with Wi-Fi Desktop phones in any location within range of your Local Area Wi-Fi Network.



Everything is pre-configured so all you need to do is,

Insert your mobile telephone SIM cards (with capped plan) into the 3G GSM slots in your  WC8350GSM PABX System and Turn on your equipment.

This advanced Hybrid GSM/Wi-Fi IP PABX System developed by iWolf offers TOTAL Mobility via the 3G GSM cellular mobile network. Combined with Wireless WIFI handsets the WC8350GSM 3G meets the high-end business communication needs of the future without the requiring and cabling infrastructure what so ever !

The iWS320-N handset incorporates a 128 x64 graphic dot matrix screen, 4 line, elegant user interface design, clear and vivid operation, with excellent experience. Equipped with DSPG chip, HD handset and HD hands free, HD encoding (g. 722), the iWS320-N provide users with a unique, vivid audio experience and greatly improves on communications efficiency.

The WC8350GSM 3G is a complete hybrid system combining the cost saving and advanced call routing features of IP telephony with the FailBack security of a traditional phone line or 3G/4G cellular mobile network.



Benefits

  • Expand to 250 Extensions
  • Make up to 200 concurrent calls
  • Provision up to 150 trunks
  • Total Portability
  • Choose a capped plan form your carrier and use the 3G/4G cellular network to make all your calls.
  • Save Time
  • Minimise you monthly spend
  • Reduced cost of ownership
  • Increase productivity
  • Streamline business processes
  • No Fuss
  • No Cables
  • No Clutter
  • No Experience Required



Ready2Go with 3 Handsets.

GO cellular with the WC8350GSM 3G wireless IP Telephone System and avoid the drama of setting up. Simply turn on the PBX system and the phones and you are good to go.



Package Contents;

1 x WC8350GSM 3G PABX System

3 x Corporate Wi-Fi (cordless) Desktop Handsets

1 x Wireless N access point with 4 port switch.

1 x Documentation and user guide.



NATION WIDE Service & Support

Phone: 1300 184  411



Advanced Feature Enhancements

As well as all the usual PBX functions, the following features are included with the base system at no additional expense. The WC8350GSM 3G offers greater interoperability and network infrastructure consolidation saving you money while streamlining efficiency and improving your business.



Surveillance

Configure one or more network cameras to peer with the WC8350GSM 3G PBX system to create a security and surveillance system ideal for any situation. Capture, record and analyse video data and monitor cameras in real-time.



Web Conferencing

Utilise real-time web conferencing to save time and improve communications with your staff and clients. Text chats and documents presentations all from within one single interface. Easily create conferences and invitations and send automatically via email. During the conference each user can select the video stream to display, chat, share files, and more. The conference administrator can also give/take control of the presentation.



Conference Room

Conduct multiuser conferences with up to 20 concurrent callers. Control the conference by setting a

mediator PIN. Set conference attributes such as user PIN, conversation recording, auto announcements, Listen only, wait for mediator, set start and finish times and maximum number of participants.



Fraud Prevention

Use this in depth telecom analytics, fraud prevention and detection tool toolkit to protect your organization. With this feature many fraud calls can be automatically prevented, Act on possible fraud attacks by receiving prompt email and/or SMS alerts triggered by different events.



Distributed DialPlans

With this feature, defining and sharing the dial-plan between one or moreWC8350GSM 3G systems has never been easier. Bring together the dial-plan of two or more branches offices in your company by configuring each PBX system with the KEY of the other. This feature makes WC8350GSM 3G systems stack-able and operate as a single communications system



Upgrades & Add-ons

The following features are available as an upgrade module. Contact a qualified iWolf representative for more detailed information.



Predictive Dialler & Call Centre Management

Deploy a professional call centre from within your WC8350GSM 3G PBX system. With this official Call Centre module system administrators are able to easily create and modify agents, outbound campaigns, create customisable forms, access client information, handle inbound calls, generate detailed reports and much more.

The Predictive Dialler component will automatically target potential customers from a list and pass the call to your telemarketers when contact has been made.



Call Monitor

This is a comprehensive monitoring solution for WC8350GSM 3G based call centres with over 150 quantitative metrics available, your call centre will operate at its top efficiency. Gather information on your telemarketers, campaigns and strategy problems. Use this information improve your campaigns.



Audio Extra

With this powerful module you can experience a unique audio integrity. Shield your customers from noisy environments, maintain a comfortable audio volume regardless of phone settings or distance from the mike and cancel echo for all participants. Ideal for conference room and web conferencing users.



Call Analytics

Regain control over your organisation’s telephony expenses in real time. This module allows you to analyse all the information in attractive, customisable reports. Analyse your telephony costs by offices, sections, extensions, trunks or dial patterns. Increase your company’s profits through a detailed costs analysis.



Advanced Operator

System operators can visually monitor detailed PBX system activity such as who is talking and to whom, call durations, calls held, queued calls, and more. Given appropriate permissions, users can also control their phone extension and perform transfers, launch call spying or whisper, monitor queue activity etc.



Hospitality and Billing

This module offers users a complete and intuitive solution for the administration of rooms tied to telephone extensions. This module is designed for hotel clientele management. Administrators will be able to manage the booking and registration of clients, see detailed information of each room status, generate personalised reports, check consumption billing, and more.



Skype Trunk Module

Integrate with Skype SIP Trunking and enable Skype users to call you on your PBX system. Call Skype users from your desktop phone.



Feature Summary:

  • Expandable to 250 extensions (IP Handsets)..
  • 4 Port Cellular 3G Gateway with 2 modules expandable to 4 modules.
  • Larger systems like the iW5260C3G can support up to 32 x GSM modules.
  • Advanced Security Features (ASF) prevents un-authorised users and hackers from using the system
  • Virtual Fax Server and Fax to Email built in. Receive faxes in PDF format ready to file electronically.
  • Analogue device support VIA optional FXS modules. Connect fax machines or cordless DECT phones.
  • Remote extension support. Connect your home office to HQ and work from home.
  • Voicemail and Voice Mail to Email.
  • Auto Attendant. Multi Level IVR.
  • Call queuing with position in the queue announcement
  • Line Monitoring
  • Conversation recording
  • Call Barge in
  • Ring Groups, Pickup Groups.
  • Music on Hold. A library of audio files available or add your own custom advertising voice over files.
  • Call Park, Call Transfer, Call Forward, Call Follow Me, Call Back.
  • Instant messaging compatible. MSN, Yahoo, Gtalk, ICQ.
  • Video phone support
  • Wi-Fi and Blue Tooth support
  • Integration with CRM and Outlook address book (single click dialing)
  • 12 month free support.
  • Renewable “Service Level Agreements” (SLAs) available.



iWolf iW3240C3G IP PBX System



System Features & Specifications

  • Up to 150 Trunks.
  • Up to 200 Concurrent calls
  • 4 Port GSM Gateway with 2 modules expandable to 4 modules.
  • Call Park. Picked up calls at any extension.
  • Call History(CDRs). Search for calls based on different criteria such as date, extension number, etc
  • Billing Report. Filter by destination, source. Calculates call charges.
  • Channels Report. (SIP, ZAP, IAX, Local, H323)
  • Call Queues with static and dynamic agents.
  • Call Queue caller management. Holds calls in the queue till available agent is located.
  • Conference Center. Supports scheduled conferences or static conference rooms.
  • Supported protocols: SIP, IAX, H323, MGCP, SKINNY.
  • Codec’s Supported: ADPCM, G.711 (A-Law & ?-Law), G.722, G.723.1 (pass through)
  • Codec’s supported: G.726, G.729 GSM, iLBC
  • Support for analog interfaces as FXS/FXO (PSTN/POTS)
  • Direct Inbound System Entry (DISE)
  • Callback
  • System resources monitor
  • The server can be shut-down from the Web
  • Operator Console
  • Server date, time, time zone configurable
  • Conversation recording. Manage recordings through the web interface.
  • Personal Voice Message Boxes.
  • Voicemail to Email Functionality (MP3)
  • Versatile IVR. Create advanced menu and submenu systems
  • Voice synthesis support
  • Echo Canceller. (Integrated).
  • Video phone support
  • DHCP server. (Integrated).
  • Support for digital interfaces such as E1/T1/J1 through PRI/BRI/R2
  • Bluetooth Support for cell phones
  • Caller ID.
  • Incoming and outgoing routes with support dial pattern matching which gives flexibility
  • Follow-me support
  • Ring groups. Advanced follow me options.
  • paging and intercom for compatible IP Phones
  • Call routing actions based on Time and date
  • Optional PIN sets



Facsimile

  • Integrated Virtual Fax Server
  • Fax visor integrated. Manage faxes (in PDF Format) via web interface.
  • Fax client software (optional) fax directly from your windows computer.
  • Fax-to-email in PDF format
  • Customisable email template (Fax-to-email)



Application Associations

  • Click to Dial with MS outlook
  • Click to Dial with integrated CRM
  • Click to Dial phone book



Instant Messaging

  • Instant Messaging (IM) server compatible with Jabber clients.
  • Start calls from the IM client (IM plug-in required).
  • Create groups of IM users
  • Connect with other IM gateways like MSN, Yahoo Messenger, GTalk, ICQ, etc.
  • Users can connect to several networks from the same IM client
  • LDAP support
  • Create server-to-server connections and share users between two servers



Supplementary

  • Integrated Billing to manage calling cards
  • Integrated Open Source CRM



Mail Server

  • Mail Server. Supports multiple domains.
  • Manages high email volumes
  • Web interface to manage emails
  • Configurable Relay Networks
  • Web based email client



Hardware Specifications

Dimensions

  • Dimensions: 440 x 440 x 150 mm).
  • Unit Weight: 6Kg



Operating Conditions

  • Operating Temp: 41º~113ºF (5º~45ºC).
  • Storage Temp: -13º~185ºF (-25º~85ºC).
  • Operating Humidity: 10~90% Non-condensing.
  • Storage Humidity: 10~90% Non-Condensing.



Power

  • Switching Type (100-240v) Automatic
  • Power Consumption: 80 Watts
  • Power Adapter: 100-240v – 50-60Hz (26-34VA) AC Input. 1.8m cord.



Codec Support

  • G.711 (A-law and µ-law)
  • G.726 (16/24/32/40 kbps)
  • G.729 A
  • G.723.1 (6.3 kbps, 5.3 kbps).
