Epygi QXE1T1 IP Telephony Gateway
$ 1745.99 Inc-Gst
Available Stock (QTY: 5+)
1 Year Nationwide Warranty
Extended warranties available
Prices Exclude Shipping
Epygi QXE1T1, Single Port PRI, T1/E1 ISDN Gateway
The QXE1T1 Gateway features 30 channels for E1 and 20 channels for T1 of compressed G.729 codec and conforms to a broad variety of voice codecs and signalling protocols.
The QXE1T1 Gateway features 30 channels for E1 and 20 channels for T1 of compressed G.729 codec and conforms to a broad variety of voice codecs and signalling protocols.
The QXE1T1 Gateway also includes call routing and auto attendant capabilities, voice prioritization over data and sophisticated firewall and security elements.
The main function of this Gateway is primarily to bridge traditional PBX traffic to the Internet, thus reducing costs and simplifying system administration.
All products are guaranteed a One Year Warranty; an additional Three Year Extended Warranty is available.
Single E1/T1 port supports 30 and 24 simultaneous calls for E1 and T1 devices respectively.
Integrating this product with any QX IP PBX allows the Gateway to then be managed through the IP PBX’s GUI.
Voice Coding:
G.711, G.726 (16, 24, 32, 40 Kbps),
G.729A, iLBC (13,33 kbit/s, 15,2 kbit/s);
VAD, CNG, G.168 echo cancellation
VoIP Encryption:
SRTP
VoIP Signalling:
SIP, SIP/TLS
DTMF:
In band & out of band signalling support
VoIP Data and Signalling Protocols
ITU-T G.711, G.726, G.729 Annex A,
G.168-2000, 2002, Q.23, Q.24;
IETF RFC 3951- iLBC;
SIP, SIPS/TLS (RFCs: 2246, 3261, 3263,
3265, 3311, 3323, 3324, 3325, 3428,
3515, 3578, 3581, 3725, 3842, 3856,
3863, 3891, 3892, 4028, 4235)
SDP (RFC: 2327, 4568)
RTP/SRTP (RFCs: 1889, 1890, 2833,
3389, 3550, 3551, 3555, 3711, 4733,
3952)
Fax over IP
ITU-T: T4, T30, T38, V17, V21, V27 ter, V29)
Primary Rate ISDN (PRI) Signaling
ITU-T: Q.921, Q.931 (DSS1), Q.951;
ETSI ETS 300 102 (NET5);
ECMA-143-(QSIG);
SR-NWT-002120 (NI2);
NTT INS1500 for Japan
PRI switch types:
DSS1, NET5, QSIG, 5ESS, NTT INS1500, DMS 100
CAS Signalling
CAS (MELCAS, ITU, ITU-T2,
ITU-T: Q.400, Q.411, Q.421, Q.422,
Q.440-Q.442, Q.450-Q.452, Q.454,
Q.455, Q.457, Q.458, Q.460-Q.468,
Q.470-Q.476;
Types: E&M Delay Dial, E&M Wink
Start, E&M Immediate Start, E&M
FGD R2 DTMF, R2 compelled, R2
non-compelled, R2 compelled with
ANI, R2 non-compelled with ANI; R2
parameters for Brazil, Mexico etc.)
ANSI T1.403.02-199, T1.403.02a-2001
Physical Interfaces
1 E1/T1 ports to the central office (RJ45)
1 LAN Ethernet 10/100 BASE-T
1 WAN Ethernet 10/100BASE TX (RJ45)
System Capacity
30 or 24 IP-PSTN calls via E1 or T1 respectively with external parties
Measurements
8.0” x 4.0” x 1.6” (20.5 x 10.5 x 4.0 cm)
Weight
1.28 lbs. (580 g)
Operating temperature
41°F – 104°F (5°C – 40°C)
Storage temperature
41°F – 140°F (5°C – 60°C)
Non-condensing humidity
5% – 90%
Power Supply
Input: 85-264VAC, 47-63Hz, AC 0.4A/115VAC, 0.2A/230VAC;
Auxiliary output power: 12.0VDC, 0.6A (max)
