iW1220E  FXO/FXS 12 Port Interface Card

$ 199.00 Inc-Gst

Available Stock (QTY: 10+)





1 Year Warranty.

Extended warranties available.

Prices Exclude Shipping.

iW1220E FXO/FXS Interface Card.

Includes 1 FXO or FXS module only.

Expand to a total of 12 modules.



iWolf’s reputation for delivering extraordinary value for your dollar on high performance gateways is well known in the communications industry. Designed specifically for IP PBX System to PSTN integration this component is perfect for hybrid and legacy telephone systems alike.

Our FXO Gateways are typically used to connect IP PBX Systems to traditional analogue telephone lines providing both permanent connectivity as well as failover protection from provider downtime.

Multiple iW1220E/P Gateways can be installed into a single system making it possible to connect almost any number of analogue (PSTN) lines from the legacy network.

National and global businesses can eliminate long distance charges by bridging their PBX systems and routing their calls through the remote FXO Gateway.



Connecting analogue telephones to PBX Systems

iWolf FXS gateways can be used to connect analogue telephones to IP PBX systems, quickly and easily. FXS and FXO modules can be installed on the same interface card, sharing its resources. The FXS module transcodes analogue voice signals into a digital signal and likewise back again for the reverse direction making a two way audio stream. The module compresses the analogue signal into a codec which is then broken into packets and transmitted across the network. The IP PBX System uses a signalling protocol to facilitate the call.



Product Description:

The iW1220P/E comes with 1 x FXO or 1 x FXS module pre-installed and is available in both PCI and PCIe bus versions.
You can add up to 11 more FXO or FXS modules to total 12 ports in any combination to meet your requirements.

iW1220P/E interface cards can be used for connecting analogue telephones and analogue PSTN lines VIA an IP PBX system. It supports any combination of FXS and FXO modules, providing a total of 12 ports. This 12 port card features interchangeable FXO and FXS module support and eliminates the need for separate banks of channels or gateways.

iW1220P/E gateways are compatible with all versions of Asterisk and is ideal for IP PBX-IVR projects along with other Open Source and proprietary switching, IVR, and SIP gateway applications.



Applications

Small Office Home Office (SOHO)

Small and Medium Business (SMB)

Gateway Termination to analogue telephones/lines



Technical Specifications

Up to 12 ports through a combination of FXS and FXO modules

Full-length analogue card

RJ45 Port

Autosense compatibility with 5 V and 3.3 V PCI busses compatible

Firmware accelerate I/O access to achieve high stability

Power: 7W Minimum, 37W Maximum at 3.3 V or 5 V.

Operation temperature: 0°C to 50°C

Storage temperature: -40°C to 125°C

Dimension: 312mm*106.7mm*16mm

Weight: 161g



Key Features:
1. Scalable: Add several cards to extend system.

2. Easy to install : Fully software and hardware compatible with Digium’s TDM400P.*  You can even use Digium’s X100M/S100M modules on this card, or use our iW-FXO / iW-FXS Modules on TDM400P.

3.Rohs is Compliant. Certificates: A-Tick, CE, FCC
