Grandstream UCM6510 PBX System

Sales, Installation, Maintenance and Support.



Overview

The UCM6510 is an innovative IP PBX appliance for E1/T1/J1 networks that brings enterprise-grade Unified Communications and security protection to enterprises, small-to-medium businesses (SMBs), retail environments and residential settings in an easy-to-manage fashion.

Powered by an advanced hardware platform and revolutionary software functionalities, the UCM6510 offers a breakthrough turnkey solution for converged voice, video, data, fax, security surveillance, and mobility applications out of the box without any extra license fees or recurring costs.



Features

1GHz quad-core Cortex A9 application processor, large memory (1GB DDR3 RAM, 32GB Flash) and dedicated high performance multi-core DSP array for advanced voice processing

1 integrated T1/E1/J1 interface, 2 PSTN trunk FXO ports, 2 analog telephone/Fax FXS ports with lifeline capability in case of power outage and unlimited SIP trunk accounts

Hardware DSP based 128ms-tail-length carrier-grade line echo cancellation (LEC), hardware based caller ID/call progress tone and smart automated impedance matching for various countries

Gigabit network port(s) with integrated PoE, USB, SD card; integrated NAT router with advanced QoS support

Strong defense against malicious attacks (Fail2ban, Whitelist, Blacklist, alerts, etc.)

Data communication via T1/E1/J1 and data-voice combined communication via T1/E1/J1 with SS7 or PRI

Supports up to 2000 SIP endpoint registrations, up to 200 concurrent calls (up to 100 SRTP encrypted concurrent calls) and up to 64 simultaneous conference attendees

Flexible dial plan, call routing, site peering, call recording (manual & automatic per SIP call & SIP trunk), control panel for endpoints, integrated NTP server & integrated LDAP contact directory

Automated detection and provisioning of IP phones, video phones, ATAs, gateways, SIP cameras and other endpoints for easy deployment

Strongest-possible security protection using SRTP, TLS and HTTPS with hardware encryption accelerator

Redundant power supply, support for Hot Standby Clustering & High Availability to minimize system down time (pending)

Automatic export of previous day’s data; periodically cleans up user data



Intergrated

  • 2 Analog Telephone FXS Ports (both with lifeline capability in case of power outage)
  • 2 PSTN Line FXO Ports (both with lifeline capability in case of power outage)
  • 1 T1/E1/J1 Interface, 1 RJ45 port
  • Network Interfaces
  • Dual Gigabit ports (switched or routed) with PoE; A 3rd Gigabit port for Hot-Standby Clustering
  • NAT Routing(user configurable)
  • Peripheral Ports USB, SD
  • LED Indicators, Power 1/2, PoE, USB, SD, T1/E1/J1, FXS 1/2, FXO 1/2, LAN, WAN, Cluster Heartbeat
  • LCD Display, 128×32 dot matrix graphic LCD with DOWN and OK buttons
  • Reset Switch



Voice/Video Capabilities



Voice and Fax Codecs

G.711 A-law/U-law, G.722, G.723.1 5.3K/6.3K, G.726, G.729A/B, iLBC, GSM, AAL2-G.726-32, ADPCM; T.38



Video Codecs

H.264, H.263, H263+



Physical

Universal Power Supply

Output: 12VDC, 1.5A

Input: 100 ~ 240VAC, 50 ~ 60Hz



Environmental

Operating: 32 – 113ºF / 0 ~ 45ºC,

Storage: 14 – 140ºF / -10 ~ 60ºC

10 ~ 90% (non-condensing)



Dimensions

440mm(L)x 185mm(W)x 44mm(H)



Mounting

Rack mount & Desktop
